Motor GPS Tracker TK115

Model NO: TK115

Product introduce:

Using GPS tracker, we can position, monitor and control the vehicle on the position server via GPRS,GPS and Internet. It can help customers to manage transparently, reduce cost, maintain security and raise efficiency. Now it is widely used in business traffic, logistics distribution, automobile lease, intelligent transportation, shipping market, army and police, rescuing, Safety Supervision, Intelligent city

Share to:
  • Introduction
  • Downloads

Using GPS tracker, we can position, monitor and control the vehicle on the position server via GPRS,GPS and Internet. It can help customers to manage transparently, reduce cost, maintain security and raise efficiency. Now it is widely used in business traffic, logistics distribution, automobile lease, intelligent transportation, shipping market, army and police, rescuing, Safety Supervision, Intelligent city

Product Feature
*Supports quad bands,i.e. 850/900/1800/1900MHz, worldwide used
*Wide Input Voltage:9-60V DC.
*GPS + GSM (LBS) Tracking
*GPS precise positioning with A-GPS and feedback position via GPRS at setting times
*Tracks real-time and playback
*Web browser platform, Smart phone app platform and SMS query.
*Supports multiple alarm, acceleration sensor can be added (B models, optional component), so as increase vibration, collision and falling alarm.
*Supports ACC status checking and vehicle status notifying.
*Use relay to remotely control the vehicle.
*Multiple protocol support, OTA upgrade program.
*Mini size, easy to hide and install
*OEM and ODM orders are welcome

Alarm Type
Vibration Alarm(Optional)
Collision / falling Alarm(Optional)
Speed Alarm
Geo-fence Alarm

Base Specification

Voltage:                                                12VDC/24VDC/48VDC/60VDC
Standby Current:                                  <10mA@12V
Work current:                                        <30mA@12V
GPS positioning accuracy:                    15m
GSM positioning accuracy:                   100m
GPS Frequency:                                   1575MHz
GSM Frequency:                                   850/900/1800/1900MHz
Hot/warm/cold start time:                       <3s,<15s,<60s
Dimensions (mm):                                 71.8(L)X38.5(W)X10.5(H)S
Operating temperature:                        -20ºC~70ºC
Operating humidity:                               20%~80%RH
Net Weight:                                            42 g


Platform
You can choose Keelin terminal monitoring platform or not. It is designed by EELINK, we can position, playback the cars’ track, listen and cut off oil of car on the platform server.
